Please note that the general floor grinding machine manufacturer is only responsible for the production of floor grinding machines, and has no professional ability to grind. Even if the price can be quoted to customers, it is generally outsourced, and there are management costs in the middle, so the customer is When choosing a civil engineering manufacturer, it is best to choose a professional system of concrete grinding system service providers, so as to ensure safety and quality and guarantee a favorable price.)
Our machine's R&D understand the floor contructer, but you don't understand it unless you have used it. The machine has been developed by experts from China Flooring Association for many years, and the working efficiency is 2-3 times that of the machines on the market. Ladies can also operate easily. Europeans and Americans highly recognize it.
Model | KD-700P | KD-630 | KD-600 | KD-850 |
Motor | 20hp(15kw) | 10hp(7.5kw) | 10hp(7.5kw) | 20hp(15kw) |
Inverter | 15kw | 11kw | 11kw | 15kw |
HZ | 50HZ | 50HZ | 50HZ | 50HZ |
Voltage | 220V~420V | 220V~420V | 220V~420V | 380V~420V |
Current | 30A | 16A | 16A | 30A |
Disc diameter | 375mm*4 | 310mm*4 | 310mm*4 | 315mm*4 |
Weight | 460kg | 318kg | 318kg | 600kg |
Work area | 700mm | 600mm | 600mm | 855mm |
Rotating speed | 300~1500rpm | 300~1500rpm | 300~1500rpm | 300~1500rpm |
Disc Quality | 12 pieces | 12 pieces | 12 pieces | 12 pieces |
Size | 2100*700*1078mm | 1260*710*970mm | 1260*710*970mm | 2100*700*1078mm |
Product Features:
1.Four grinding discs adopt gear-to-turn transmission design
2.The main plate and the planet disk are driven independently to ensure the flatness of the ground
3.Ground grinding can estimate the workload of one day and facilitate the development of construction plans
4.One-button cruise control, drive control system automatically walks, liberating labor safe and efficient
5.Set parameters to ensure the working speed of the grinder and the stability of the grinding pressure to achieve precise grinding
6.Integrated integrated control system design, with universal wheel system, reducing labor intensity and improving construction efficiency
7.Large industrial vacuum cleaner can be configured to achieve dry and wet floor grinding mode
8.Set the walking speed of the grinder to realize the ramping of the up and down slope
9.One-piece laser cutting aluminum alloy gear box, the device weight 588KG achieves fast and efficient grinding
10.Intelligent technology dust-free grinding, responding to the strategic layout of national environmental protection policies
Product/User Benefits:
Increased productivity and grinding performance
Easy handling thanks to ergonomic control elements, fixed speed as well as low noise and vibration levels- Fatigue-proof working and reduction of side forces because of outstanding machine balance
- Maximum durability and load capacity due to very robust construction
- Impressive mobility as well as trouble-free transportation thanks to detachable machine parts
- Time saving patented quick tool fixing system
- Dust-free operation because of floating cover in combination with reliable dust collection system
Fields of applications:
- Grinding concrete/epoxy floor/ solidified floor/ terrazzo floor /granite floor /natural marble floor /diamond abrasion resistant floor /self leveling cement,etc ,places requiring surface treatment
- Removal of paint, epoxy, glue and other coatings from concrete
- Preparation of concrete for installation of new flooring/coating
- Elimination of irregularities in concrete
- Repair of damaged concrete
- Sealing preparation
- Renovation works
Product Features:
- It is safer to use IP67 waterproof and dustproof power plug
- High-power heavy-duty body can improve the cutting rate of ground, the ash output is large and the efficiency is high.The back-and-forth reversible counterweight iron is adaptable to a variety of surfaces.Achieve double efficiency, perfect effect!
- Famous brand frequency converter with super variable speed control function, the national joint protection without worries
- Original patented retractable compensation structure, suitable for uneven ground, reduce dust and flying stone, improve construction environment safety
- With toolbox, portable storage of accessories
- The frequency conversion motor can meet the grinding requirements of industrial floor for a long time and heavy task, and can work continuously for 24 hours.
- Multi-functional magnetic disc is convenient to install, limit pile locking disc, construction is safer
- Fault detection, through the fault code according to the reference table to find out the corresponding problems
FAQ:
Q1:Are you trading company or manufacturer?
A1:We are manufacturers and we have our own factories. specializes in floor grinder products and has 15 years of flooring experience. Welcome to visit our factory, we can also provide the best suitable flooring construction solution for you.
Q2:What are the advantages of your products compared with other products?
A2:Our products are excellent in terms of productivity, handling, reliability and construction results. Products warranty for 3 years, however other grinder brand warranty is only 1 year.
Q3:Are the grinders will come with accessories?
A3:es,all the grinders include tool box and necessary accessories.
Q4:Can the grinders bi used for polishing?
A4:Yes,of course. They can do both grinding and polishing.
Q5 :Can you customize the machine for the customer?
A5:Yes. We can, we also provide OEM for customers; If you need customized services, please contact us
Q6:What is the MOQ?
Q6:We usually provide 1 set for customers to test.
Why do you choose us?
1.We have high inquiries and sales quanlity on other website in addition to alibaba , which means our products are so popular.
2.High cost performance. With the same quality and function, our price is competitive in the market
3.Floor machine industry pioneer in china, to participate in the exchange and exhibition, the products are widely used in southeast Asia, Europe and the United States and other markets
4.High quality products, high effect,easy to learn and easy to operate, even if it is a heavy machine, a woman can operate
5.Research and development ability. each product is patented
6.Teach you how to operate as well as quality assurance, after-sales service
