| Description | unit | parameter |
| Model No. | | ZXX - C1812 |
| Colum | Set | Heavy iron |
| | | China |
| Control System | set | Leetro |
| Axis | PC | Cutter change : by hand |
| | | Diam:¢125 |
| | | coller:cool water |
| | | RPM:42000 RPM 2800 |
| | | POWER:1.5KW 4.5KW |
| Drive | set | YMPC |
| Invertor | kw | BEST : 11KW |
| Work table size | mm | 1800*1200MM |
| Max Process Glass | mm | 1400*1000mm |
| Z-axis space height-open | mm | 380 |
| motor | set | China |
| Internal of machine structure | set | Half cover/ waterproof design |
| Work table load weight | KG | 120 |
| Positioning accuracy | mm | 0.01 |
| Repeated positioning accuracy | mm | 0.01 |
| Cutting speed | M/MIN | 0-2M/MIN |
| Grinder speed | M/MIN | 0-12M/MIN |
| Stroke protection | PC | Omron,Japan |
| GEAR | PC | GERMAN DMJ-1.5M High precision |
| Limit switch | | CHIIB |
| Guide Screw bearing | PC | HIWIN |
| | | Model: Z axis with diagonal contact |
| Lubrication system | set | Origin : |
| | | Lubrication automatically |
| Cooling type | set | Water pump |
| Main axis cooling | set | Automatic thermostat cooler |
| Main electric | | CHNT/Schneider |
| Volt./Frequecny | KW | AC/380v/10KW/50HZ (AS PER CUSTOMER REQUEST) |
| Machine Size | mm | 1900x2700x2300mm |
| weight | KG | 1600 |
| power | KW.H | 11.1 |
